 So I did a pie cut.

Had a small flashlight in my mouth since I was in a hurry and needed both hands for the cutoff wheel.

When I got through the bolt the motor went "snap" and jumped up an inch and forward about 2.

Scared the crap out of me I think I jerked so hard I might have chipped a tooth with the flashlight.

Took the O sensor plugs off, and 2 plugs to the transmission. Motor STILL isn't out, the trans lines are attached somewhere under the passenger motor mount plate.

If I find that then the motor would come out, the TC stayed in everything looks fine.

I can't push it around till I fix the right rear brake drum....
